Narrow aisle lift trucks function by increasing the ratio of the storage space to the width of the aisle. Yale features the single reach NR and the double reach NDR units for aisle widths of eight to ten feet. The Narrow Aisle trucks made by Yale offer a Quadra-Flexx Operator Compartment which has various stance and control handle configurations and use best-in-class ergonomics.
NDR & NR Productivity Enhancements
Quadra-Flexx Operator Compartment: There are numerous control handle configurations which meet a variety of operations and the aft stance, a choice of fore or side-stance options too.
AC Motor Technology: The AC motor technology offers fast lifting speeds along with strong deceleration and acceleration. It has been made for quick plugging so as to facilitate more responsive directional changes which combine to increase the amount of cargo transported in a shift.
Reach & Mast Assembly: The trunion mounting and tapered roller bearings are part of the mast reach assembly. This increases the mast durability and rigidity; along with the gusseted rear frame weldment, as well as the reach assembly carriage that are reinforced for long life.
Power Lowering: Yale offers industry leading lowering speeds and these uploaded speeds really improve the overall throughput and productivity.
Regenerative Lowering: While regenerative lowering could reduce battery changes per shift it also functions to maintain a lower oil operating temperature.
Electronic Steering: In order to greatly reduce energy, the electronic steering eliminates the need for hydraulic pumps. The steering tiller is adjustable by the operator and the steer effort is actually technician adjustable so as to decrease operator fatigue. During the start-up process, drive tire centers start automatically.
Order Selectors: The very narrow aisle trucks and the narrow aisle trucks are also referred to as order pickers. These equipment are designed for the manual handling of racked loads that are smaller than pallet size. These order selectors raise both the operator and the cargo to its required height. This height could be more than 30 feet. Similar with most turret trucks they are usually wire or rail guided when utilized in very narrow aisle applications.
